Minelab Equinox 800 Series Metal Detector – Fully Waterproof
In stock (can be backordered)Add to wishlist1Add to compare
Minelab Equinox 800 Metal Detector – 100% Waterproof
** 15% Military Discount Available for US Active or Retired Vets. **
** Free 2022 Prospectors/Treasure Hunters Bundle Package – Only available from Rob’s Detector Sales **
- Jobe 14.5″ Prospecting Pick
- Andy Sabisch’s new 2021 Version Equionx Book – Must have!
- Doc’s SCOOP Pouch
- Plastic Digging Scoop (choose your color – Green, Yellow, Red or Black)
- Doc’s Padded Equinox Control Box Cover and Armrest Cover Kit
- Minelab Baseball Cap
- Shipping, Handling and Full Insurance value on package shipped to the US Only, NO International Shipping available
- Lifetime Support – Email, Phone, Text and Forum Support Beyond the Sale.
Representing our most significant coin & treasure introduction since the launch of the CTX 3030 in 2012, Minelab is pleased to announce the pending release of our new EQUINOX Series Metal Detectors.
The EQUINOX Series is the all-terrain multi-purpose detector that obsoletes all single frequency VLF detectors. Equally adaptable for all target types and ground conditions… just select your detecting location and go!
The EQUINOX Series has been designed for the serious coin & treasure enthusiast looking to upgrade to a high performance detector, without the high cost. It’s also suitable for the new detectorist, having several pre-set modes for different detecting locations. The EQUINOX Series features Minelab’s STATE-OF-THE ART Multi-IQ simultaneous multi-frequency technology and combines fast recovery speed with low-latency wireless audio in a lightweight waterproof platform.
4 Detect Modes (Park, Field, Beach, Gold)
6 Frequency Options (5kHz, 10kHz, 15kHz, 20kHz, 40kHz, Multi)
Bluetooth Headphones and WM 08 Wireless Module Supplied
The above diagram is intended to be a simplified representation of how different frequencies of operation are better suited to different target types; i.e. low frequencies (e.g. 5kHz) are more responsive to high conductors (e.g. large silver targets) and high frequencies (e.g. 40kHz) are more responsive to low conductors (e.g. small gold nuggets). The EQUINOX 600 offers a choice of 3 single frequencies and the EQUINOX 800 offers the choice of 5 single frequencies. Both models also have simultaneous multi-frequency options that cover a much broader range of targets than any one single frequency can – and they’re different across the Detecting Modes!
“EQUINOX, with Multi-IQ, has the potential to obsolete all the traditional VLF detectors that enthusiasts have been using for decades.” –Minelab Electronics Pty Ltd.
Detect Modes – 4 Modes – Park, Beach, Field, Gold
Custom Search Profiles – 8 (2 per Detect Mode)
User Profile Button – Yes
Operation Frequencies (kHz) – Multi, 5, 10, 15, 20 & 40 kHz
Noise Cancel – Auto, Manual (-9 to 9)
Ground Balance – Auto, Manual
Sensitivity Level – 1 thru 25
Target Volume Level – 0 thru 25
Threshold Level – 0 thru 25
Threshold Pitch – 0 thru 25
Target Identification – 50 Segment Notch Discrimination, Ferrous -9 thru 0, Non Ferrous 1 thru 40
Target Tones – 1, 2, 5 or 50 tones
Tone Break – Ferrous or Non-Ferrous
Tone Pitch – Ferrous or Non-Ferrous
Tone Volume – Ferrous or Non-Ferrous
Depth Indicator – 5 Levels
Length of Detector – 1440 mm or 56.7 inches
Weight of Detector – 1.34 Kg or 2.96 lbs
Standard Searchcoil Size – 11″ Double D Smart coil with skidplate (waterproof)
Audio Output – In Built Loudspeaker, 1/8″ Headphones (included), Bluetoogh Compatible, WM 08 Wi-Stream compatible
Headphones – (Included) Bluetooth and aptX Low Latency Headphones (non waterproof)
WM 08 Module Included – Yes
Display – Monochrome LCD with backlight
LCD Blacklight – Low, Medium, High or OFF
Battery – In-built rechargeable Li-Ion battery
Battery Runtime – Approx 12 hours on fully charged battery
Waterproof Detector – Yes 3m or 10 foot
Key Technologies – Multi-IQ, 5Fx8, Wi-Stream, Bluetooth, aptX Low Latency
Other Accessories – USB Charging Cable, Multi Language Screen Protectors
Software Upgradeable – Yes, via USB Connection (Windows and OSX)
Warranty – 3 years from date or purchase (control box and coil)
